FLAIL MOWER KDH

Product Description

FLAIL MOWER KDH

FLAIL MOWER KDH

Uses:

Shredder with adjustable offset, for working on grass,leaves, vine and olive remains. The KDK model is aversatile machine, suitable for mowing grass and aboveall shredding twigs and pruning residue, thanks to therobust structure and equipment. The machine can bemoved sideways with a mechanical or hydraulic system(optional). Robust structure suitable for professionaluse. Maximum application versatility on any type ofresidue, from open fields to orchards. Rear bonnet canbe opened for maintenance purposes. Standard skidsscrewed to the side.

Model	KDH 180	KDH 200	KDH 220	KDH 240
Dimensions(mm)	200010851070	220010851070	240010851070	260010851070
Structure Weight (kg)	480-538	547-608	560-621	625-685
Cutting width (cm)	180+58	200+58	220+58	240+58
Cutting height (mm)	0-60	0-60	0-60	0-60
Rotor diameter (mm)	159	159	159	159
Hammer Number	16	18	20	22
Side shift distance	348	348	348	348
Belt No.	4	4	4	4
Output of motor		20-30L/min
No.of blade for side disc		2PCS
Disc Diameter		580 mm
Motor speed		2200r/min
Working pressure		18Mpa
Power Required (hp)	45-70	50-80	50-90	50-90
